Demolition MultiSystem | Earthworm Attachments NZ
Attachments / Shears & Pulverisers / Demolition MultiSystem

Demolition MultiSystem

Versatile, precise hydraulic crushing

With five different jaw kits available, this is the Swiss army knife of heavy hydraulic tools. Choose the ideal jaws for the job, whether it be crushing concrete, cutting rebars, processing scrap or cutting sheet metal. The MBI Multisystem offers a cost-effective solution for getting more from your fleet – without sacrificing performance or power.

Got questions? We’re here to help:

Request a quote
0508 21 22 23

Ideal for:

Demolition, decommissioning, mining, recycling, material recovery

Adapting to primary and secondary demolition applications

High reach demolition

Features

Powerful inverted cylinders capable of crushing reinforced concrete

360° hydraulic rotation for precise positioning in high reach demolition

Unique central single-pin design to allow for quick replacement of the various leg kits

Speed Valve reduces opening and closing times

Interchangeable teeth and blades to reduce downtime

Demolition MultiSystem Specifications

ModelMS09RMS15RMS22RMS28RMS50RMS140R
Excavator weight with MS bucket place (ton)10-1516-2021-2728-4045-55120-160
Excavator weight with MS stick place (ton)7-1010-1512-1815-2428-3880-120
Hydraulic working pressure300-320320-350320-350320-350320-350320-350
Oil flow (L/min)90-120130-150180-220220-250250-300700-1000

Available Jaw Sets

CR Crusher Jaws

Exceptional power for primary crushing of concrete structures

CP Pulveriser Jaws

Ideal for secondary demolition and rebar separation

CC Combi Crusher Jaws

Combined crushing and shearing capability to demolish heavily reinforced concrete

SH Shear Jaws

Demolition of iron structures, scrap processing

PSH Plate Shear Jaws

Quick demolition of sheet metal structures such as tanks, silos, basins, and containers

Download

Download the info guide with specifications and pricing

Talk Demolition Attachments with our technical team

Fill in the form to request a callback or more information

More Shears and Pulverisers
